RGB-LEDIPCB 1x WS2812

Description

KAmodWS2812-1 module allows to create lighting effects of any color, and thanks to the controller built into the WS2812 diode, it is possible to combine modules into rows, creating any shapes. Regardless of the number of connected LEDs, the control is transmitt with using one signal cable.

Features

• Tri-color LED (RGB) WS2812 type, with embedded controller
• Possibility of series connection of additional modules without extra signal lines
• Each of basic colors can controlled with up to 256 brightness levels
• Possibility of displaying more than 16.7 mln light tone
• Power supply voltage: 5...7V
• Wire that connects two modules can be up to 5m length without additional amplifier
• Holes for soldering of pin connector
• Two mounting holes 3mm
• Module size (without connectors): 18mm x 11.5mm x 3.5mm

Kit content

• KAmodWS2812-1 module
• Two 3-pin connectors (male straight) for soldering
