Owon HDS242 HANDHELD SCOPE 40MHz 2CH View larger

Owon HDS242 HANDHELD SCOPE 40MHz 2CH

HDS242

6 Items

In stock

Manufacturer homepage

206,00 €

Owon HDS242 is a 40MHz bandwidth digital handheld oscilloscope with two channels, DMM functions and USB-C connection.

Features

  • Oscilloscope + multimeter + waveform generator, multifunction in one
  • 3.5-inch high-resolution, high-contrast color LCD display, suitable for outdoor use
  • 18650 lithium battery, comprehensive power consumption ≤3W, can work continuously for about 6 hours
  • USB Type-C interface, support power bank, support PC software connection
  • Self-calibration function
  • SCPI supported, facilitate secondary development

Specifications

Oscilloscope Specifications

ModelHDS242HDS272HDS242SHDS272S
Bandwidth40MHz70MHz40MHz70MHz
Channels2-CH Oscilloscope2-CH Oscilloscope+1-CH Generator
Sample Rate250MSa/s
Acquisition ModelNormal, Peak detect
Record Length8K
Display3.5-inch LCD
Waveform Refresh Rate10,000 wfrms/s
Input CouplingDC, AC, and Ground
Input Impedance1 MΩ±2%, in parallel with 16pF±10pF
Probe Attenuation Factors1X,10X,100X,1000X,10000X
Max. input Voltage400V (DC+AC, PK-PK, 1MΩ input impedance) (10:1 probe attenuation)
Bandwidth Limit (typical)20MHz
Horizontal Scale5ns/div - 1000s/div, step by 1 - 2 - 5
Vertical Sensitivity10mV/div - 10V/div
Vertical Resolution8 bits
Trigger TypeEdge
Trigger ModesAuto, Normal, single
Automatic MeasurementPeriod, Frequency, Mean, PK-PK, Max, Min
Cursor MeasurementΔV, ΔT, ΔT&ΔV between cursors
Communication InterfaceUSB Type-C

Multimeter Specifications (Standard)

Max. Resolution20,000 counts
Testing ModeVoltage, Current, Resistance, Capacitance, Diode ,and Continuity test
Input Impedance10MΩ
Max Input VoltageAC 750V, DC 1000V
Max Input CurrentDC : 10A AC : 10A
Diode0 - 2V

Waveform GeneratorSpecifications (Only for HDS242S & HDS272S)


Frequency Output
Sine0.1Hz - 25MHz
Square0.1Hz - 5MHz
Ramp0.1Hz - 1MHz
Pulse0.1Hz - 5MHz
Arbitrary0.1Hz - 5MHz
Sampling Rate125MSa/s
Channel1-CH
Amplitude Range20 mVpp - 5 Vpp
Waveform Length8K
Vertical Resolution14bits
Output Impedance50Ω

Links

Video

click for more info
ManufacturerOwon
Manufacturer's modelHDS242
Measures198 x 96 x 38 mm
Weight0,6kg
Channels2
Size3.5 inches
Resolution320x240
Bandwidth40Mhz
Sample memory8K
Sample rate250MS/s
Sample resolution8bit
