Serial Interface
- Interface: Software-selectable RS232, RS422 or RS485 (2 and 4 wire support)
- Connectors: 2 DB9M DTE serial ports
- Data Rates: Software-selectable baud rate from 300 to 921 KBaud
- Characters: 7 or 8 data bits
- Parity: odd, even, none
- Stop Bits: 1 or 2 Control
- Signals: CTS/RTS (Hardware)
- Flow Control: XON/XOFF (Software)
Network Interface
- Interface: 10Base-T/100Base-TX Ethernet port
- Software selectable Ethernet speed 10/100/Auto
- Software selectable Half/Full/Auto duplex
- Connectors: RJ45
- Standards: ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, and RFC2217
