RASPBERRY RACK 19" 4xSlot 58x30mm 1.33U

UM-SBC-213 Rackmount Kit is a durable and professional solution for mounting up to four Raspberry Pi or compatible single-board computers (SBCs) into a 19″ server cabinet. Thanks to its 1.33U height, it provides extra space for integrating components such as PoE HATs or UPS modules – making it an excellent choice for advanced server or testing environments.

Features

• Compatibility: Raspberry Pi 2B, 3B, 3B+, 4B, 5, and other SBCs with Raspberry Pi form factor
• Capacity: Mounts up to four devices in a single 1.33U rack enclosure
• Mounting: Each device is secured with four M2.5 screws (included in the package)
• Additional Space: Increased height allows for more flexible add-ons such as cooling or power management modules
• Cable Management: Includes cable ties for clean and organized wiring

Technical Specifications

• Rack Size: 19″, 1.33U
• Dimensions (W x H x D): 482.6 × 58.2 × 210 mm
• Material: Steel
• Color: Front panel: White aluminium (RAL 9006), frame panel: Black (RAL 9005)
• Fan Compatibility: 4x 40×40 mm (mounting hole spacing 32×32 mm), mounted with two screws per fan
• Telescopic Rails (optional): 200 mm slide-out rails for easy maintenance

Package Contents

• 1x UM-SBC-213 Rackmount Kit
• 4x Rack mount screw sets
• 10x Cable ties 100 mm
• 5x Cable ties 300 mm
• 20x M2.5 mm screws for SBC mounting
• 1x Product data sheet
• 1x Assembly instructions

Note!

• Computers (e.g., Raspberry Pi) are not included

Links

• Product Data Sheet (PDF)
